Description
CP 12.0 280V P2 AL 30×58 PI M8 OIL
-
Can: Aluminium
-
Self healing polypropylene winding lm
-
Filling material: Liquid, based on vegetable oil, non-PCB
-
Protection class: B, with overpressure protection
-
Max. operating temperature of case: 100°C
-
Test class: 40/100/21
-
Discharge resistor: yes, <50 V within <60s
-
Conforming with IEC/EN 61048 and IEC/EN 61049
| Technical Data | |
| Rated supply voltage | 280 V |
|
Mains frequency
|
50 / 60 Hz
|
| Capacitor tolerance | ±5% |
| Operating temperature | (negative) 40 … +100°C |
| Push-in terminal | 0.5 – 1.5 mm2 for rigid wires |
| Capacity | Type | Article Number | Mounting | Diameter d | Length L | Height |
| 12 μF | CP 12.0 280V P2 AL 30×58 PI M8 OIL | 9100613 | M8 | 30 mm | 58 mm | 20 mm |
