OGH450/280-101W 230/240V 50HZ

SKU: 89122895 Category: Tags: ,

Description

OGH450/280-101W 230/240V 50HZ

Wattage Voltage Current Length  Type Article Number Loss Hot Input Power Lamp Current Lamp Start Current  Circuit P F Line Current Line Start Current Capacitor Winding Stack Figure Length Mtg Centres Weight
W V mA mm     W W A A cos ø A@0.9PF A@0.9PF μF0.9PF Δt mm   mm mm kg
230 V 50 Hz – OG ballasts
Metal halide
450 135 3.7 OGH450/280-101W 89122895 34 484 3.7 5.7 0.57 2.34 3.78 30 50 60 2 140 111-127 4.3

240 V 50 Hz – OG ballasts
Metal halide
450 135 3.7 OGH450/280-101W 89122895 36 486 3.7 5.63 0.55 2.25 3.59 30 50 60 2 140 111-127 4.3

Additional information

Weight 4.3 kg
