Description
OGS400 -106 240V 50Hz TRAT LL
Lamp | Ballast | Electrical | Thermal | Physical | |||||||||||||||
Wattage | Voltage | Current | Length | Type | Article Number | Loss Hot | Input Power | Lamp Current | Lamp Start Current | Circuit P F | Line Current | Line Start Current | Capacitor | Winding | Stack | Figure | Length | Mtg Centres | Weight |
W | V | mA | mm | W | W | A | A | cos ø | A@0.9PF | A@0.9PF | μF0.9PF | Δt | mm | mm | mm | kg | |||
240 V 50 Hz – OG ballasts | |||||||||||||||||||
Metal halide | |||||||||||||||||||
400 | 100 | 4.6 | – | OGS400-106 | 89121086 | 34 | 434 | 4.6 | 5.8 | 0.39 | 2.01 | 2.66 | 45 | 60 | 70 | 2 | 160 | 131-147 | 4.9 |
High-pressure sodium vapour | |||||||||||||||||||
400 | 100 | 4.6 | – | OGS400-106 | 89121086 | 34 | 434 | 4.6 | 5.8 | 0.39 | 2.01 | 2.66 | 45 | 60 | 70 | 2 | 160 | 131-147 | 4.9 |
