OMS 150-26 K 220/240/50 105C155 CMP 05_0.800

SKU: 89001109 Category: Tags: ,

Description

OMS 150  -26 220/240V 50HZ TRAT

Lamp Ballast Electrical Thermal Physical
Wattage Voltage Current Type Article Number Loss Hot Input Power Lamp Current Lamp Start Current  Circuit P F Line Current Line Start Current Capacitor   Stack Length Mtg centres Weight
W V mA     W W A A cos ø A@0.9PF A@0.9PF μF0.9PF Δt mm mm mm kg
220 V 50 Hz – OM ballasts
Metal-halide & High-pressure sodium
150 100 1.8 OMS150-26 89001109 18.5 168.5 1.8 2.3 0.43 0.85 1.14 20 55 105 155 141 2.5

240 V 50 Hz – OM ballasts
Metal-halide & High-pressure mercury vapour
150 100 1.8 OMS150-26 89001109 20 170 1.8 2.3 0.39 0.79 1.06 18 55 105 155 141 2.5

Additional information

Weight 2.55 kg
